ETX-2

When looking for next-generation IP and Carrier Ethernet Networking Interface Device (NID), also known as Network Termination Unit (NTU), the Resilient ETX-2 line of next-generation offers advanced demarcation for SLA-based business services, wholesale services and mobile backhaul. A Network Termination Unit (NTU) serves as the crucial endpoint that connects customer premises to the carrier’s network, providing the necessary interface for Ethernet services. NTUs are responsible for managing traffic, ensuring quality of service (QoS), and monitoring network performance to meet stringent SLA requirements.

Description

ETX-203AX: Carrier Ethernet Demarcation Device

ETX-203AX is ideal for carriers, service providers, and wholesale operators requiring advanced Ethernet functionality at customer premises and multi-tenant units (MTUs).

Four and six FE/GbE ports; flexible selection of SFP and copper interfaces
Outdoor enclosure option
Wide range AC/DC power supply

ETX-203AM: Universal Carrier Ethernet Demarcation Device

Available as a modular demarcation device, the ETX-203AM enables operators to deliver Carrier Ethernet services and L2 VPNs over any network connection.

Four FE/GbE user ports
Modular network interfaces: FE/GbE (combo), E1/T1, T3, VDSL, or SHDSL

ETX-203AX-T: Carrier Ethernet Device with LTE/Broadband Connectivity

ETX-203AX-T extends Ethernet VPN services to new, out-of-reach locations, allowing rapid site commissioning by using readily available LTE or broadband networks. The ETX-203AX-T enables cost-effective Ethernet VPN services backup using LTE or broadband. Additional cost optimization can be achieved by splitting traffic between a service-assured VPN and best-effort LTE or broadband access.

Five FE/GbE ports with flexible selection of SFP and copper interfaces
Optional built-in LTE modem with global service coverage
Secure EVC tunneling over private IP/LTE networks or over the internet using L2oGRE or L2TPv3 protocols
Full suite of MEF CE-2.0 capabilities for SLA monitoring, diagnostics and fault detection
Fragmentation and IPsec support
Data and management protection using LTE or broadband
Integrated wide-range AC/DC power supply

ETX-205A: Carrier Ethernet/Mobile Demarcation Device

The ETX-205A provides advanced Carrier Ethernet demarcation and offers combo interfaces and power supply redundancy. For LTE/LTE-A mobile backhaul, the ETX-205A is installed at cellular tower and controller sites to guarantee differentiated SLAs.

L2 VPN service demarcation with superior traffic management and monitoring capabilities
Flexible synchronization offering Sync-E, IEEE 1588v2 slave, BC and TC for frequency and phase synchronization in mobile networks
Distributed GM^TM architecture integrating built-in GPS receiver with IEEE 1588v2 Grandmaster functionality for cost-optimized LTE deployments
E1/T1 pseudowire services per MEF-8, UDP/IP, MPLS static labeling in SAToP and CESoP modes, and with CAS

ETX-220A: 10G Carrier Ethernet Demarcation/Aggregation Device

The ETX-220A combines intelligent demarcation and aggregation capabilities to deliver SLA-based Carrier Ethernet services for enterprise and carrier-to-carrier E-Access applications.

Up to four 10-GbE ports and up to 20 x 1-GbE ports in various combinations
Flexible synchronization offering Sync-E, IEEE 1588v2 slave, BC and TC for frequency and phase synchronization in mobile networks
